TIG Welder - 315 A - 400 V - digital - pulse - water-cooled

2,679.⁰⁰€ Prices incl. VAT

(0)

Preview: TIG Welder - 315 A - 400 V - digital - pulse - water-cooled

TIG Welder - 315 A - 400 V - digital - pulse - water-cooled

360° photo

2,679.⁰⁰€

Prices incl. VAT

Free shipment to Ireland
?

Ready to ship today, Delivery time appr. 6-12 workdays
30 days return service
?
3 years guarantee

Product highlights

TIG AC/DC / MMA
315 A / 400 V
Digital / pulse
Welding strength: 10 mm
Water-cooled

Powerful—TIG AC DC up to 315 A and 60 % duty cycle with water cooling
Versatile—TIG AC, TIG DC, pulse, MMA
Precise—pulse function with adjustable pulse frequency up to 200 Hz
Modern—digital menu navigation for precise results
Mobile—with wheels and handle

The TIG welder for ambitious welding jobs

The powerful TIG welder ENTRIX315AW convinces with precise welding results that exceed every expectation. The integrated water cooling system guarantees optimal welding results even at a welding current of 315 A. With the TIG welding method, you can weld with direct current (DC) or alternating current (AC), meaning you can even effortlessly weld aluminium. You can also use the pulse function or use the device for MMA welding.

Optimum welding results for TIG AC / DC thanks to water cooling

The TIG welding machine's digital control panel is very clearly arranged. Each of the parameters can be simply selected and the desired value for gas post-flow time or end current, for example, set using buttons. Other common operating modes for TIG welding, such as the choice between DC or AC mode or easy switching between 2- and 4-stroke welding, can be easily and directly set on the control panel. The integrated water cooling system enables optimum welding results when welding with high welding current values. When water-cooled, the MMA welder with an impressive 315 A can weld nearly all melting types of metal and their alloys such as aluminium, copper, nickel or steel.

For TIG welding, simply activate the pulse frequency on the control panel which will enable you to precisely weld thin sheets, among other things. You can select various parameters such as pulse frequency, pulse current or base current. You can precisely set the value, which is shown on the large display, using two buttons. Alternatively, you can also control the welding current using a foot pedal. The Easy mode automatically matches all other parameters to the selected current.

For MMA welding, you should first set the strength of the of the welding current on the control panel. For balanced welding results, the device is equipped with the functions Hot Start, Arc Force and Anti-Stick. MMA welding is primarily used for iron or steel, as well as for alloys such as cast iron or copper. The cart is equipped with four wheels to facilitate mobility and has space for gas cylinders needed during TIG welding.

This device does not include a high voltage plug!

Model

ENTRIX 315AW

Condition

New

Functions

TIG DC, TIG AC, Pulse, MMA

Material, housing

Steel

Rated input voltage

400 V / 3 phases

Frequency

50/60 Hz

Rated input current

TIG 11 A

MMA 18 A

Max. input current

TIG 21 A

MMA 24 A

Rated input power

11 kVA

Max. input power

20,75 kVA

Open circuit voltage

59 V

Ignition (TIG)

HF - high-frequency

Welding current TIG-DC

5 - 315 A

Welding current TIG-AC

15 - 315 A

MMA welding current

20 - 280 A

Duty cycle

50 % (TIG)

60% (MMA)

Welding current at 100 % duty cycle

250 A (TIG DC)

250 A (TIG AC)

250 A (MMA)

Welding current at 60 % duty cycle

280 A (MMA)

Welding current at 50 % duty cycle

315 A (TIG DC)

315 A (TIG AC)

Pulse current

5 - 315 A

Pulse frequency AC

0,5 - 200 Hz

Pulse frequency DC

0,5 - 200 Hz

Pulse width

5 - 95 %

Frequency of output current (AC)

40 - 200 Hz

Balance (AC) Clean Scope

30 – 70%

Balance (AC) Clean Width

30 – 70%

Upslope time

0,1 - 15 sec

Downslope time

0,1 - 25 sec

Gas magnetic valve

Yes

Gas pre-flow time

0,1 - 1 sec

Gas post-flow time

0 - 15 sec

Diameter, electrode (TIG)

1,6 - 3,2 mm

Diameter, electrode (MMA)

1 - 5 mm

Welding strength

0,5 - 10 mm

Pulse switch

Yes

ARC force

Yes

Hot start

Yes

Anti-stick

Yes

Connection for foot pedal

Yes

2 T / 4 T

Yes

Length of electrode holder with cable

3 m

Length, ground cable

3 m

Length, TIG hose package

5 m

Length, power cable

4 m

Insulation class

Protection class

IP21S

Device cooling

Fan

Power factor

0.93

Efficiency (below rated power)

≥ 0.85

Torch cooling

Water

Integrated water cooling

Yes

Power, water cooler

260 W

Flow rate, water cooler

8 L/min

Dimensions (LxWxH)

94 x 45 x 116 cm

Weight

72,64 kg

Shipping dimensions (LxWxH)

101 x 51 x 122,8 cm

Shipping weight

88,18 kg

Manual

Download PDF

Delivery Package

Welder ENTRIX 315AW
Water cooler
TIG welding torch with hose package, 5 m
MMA clamp with cable, 3 m
Grounding cable with clamp, 3 m
Air hose
3 chains
3 ceramic gas nozzles (5, 6, 7 mm)
3 clamping sleeves (1.6 / 2.4 / 3.2 mm)
Clamping sleeve housing
Foot pedal
Tungsten electrode 2.4 mm
Long torch cover
Short torch cover
2 clamp rings
Instruction manual

MOSFET

The welder is equipped with a MOSFET transistor. This technology represents the highest standards of performance combined with compact and lightweight design. The result is 93% efficiency! The welding current is very stable and thus ensures a perfect weld.

Show moreShow less

PROTECTIVE GAS

TIG/MIG and MAG welding require a protective gas. Inert gases, such as argon and helium, as well as active gases (for example carbon dioxide) and other mixtures can be used. The solenoid valve regulates the flow of gas. The valve is operated via a button on the torch.

Show moreShow less

EARTHING SYSTEM

On the back of every welding machine is a screw with an earthing mark. Before use, earth the unit via a cross-section cable, which must be at least 6 mm².

GROUND TERMINAL CONNECTOR

MMA WELDING CABLE CONNECTOR

TIG TORCH CONNECTOR

FOOT PEDAL CONNECTOR

This unit can also be operated using a foot pedal.

SUPPLY VOLTAGE

This device works with a 3-phase connection (400 V +/- 10 %).

COOLING SYSTEM CONNECTIONS

If welding with more than 200 A it is recommend that a cooler is used. The connections of the welding device and the cooler-lines are marked accordingly with colours.

NON-CONTACT HF-IGNITION

A non-contact high-frequency ignition in TIG mode ensures a cleaner weld starting point.

GAS PRE-FLOW TIME

This is the time taken from the moment of pressing the torch button to that of the electric arc igniting. During this process the solenoid valve opens and the released gas pushes the oxygen from the gas lines and in doing so, forms a protective atmosphere for the arc.

Show moreShow less

STARTING CURRENT

Value of the arc ignition output current. This current can be adjusted at will. For precision welding, it is recommended to start with reduced power, weld smoothly and eventually adjust the current accordingly.

Show moreShow less

CURRENT RISE TIME

The time taken by the output power to rise to that of the welding current’s value.

WELDING CURRENT

DOWN SLOPE TIME

The time taken of the output welding current to lower to that of the terminal current.

FINAL CURRENT

The output current value before the end of the weld. Welding with the final current helps prevent a crater forming at the end of the weld.

GAS POST-FLOW TIME

The time after the weld is finished in which gas continues to flow from the torch; this cools the burner and protects the weld from oxidation.

PULSE

This function reduces the heat to the material. It is primarily suitable for welding thin plates. If MIG welding is used, it is perfect for aluminium welding.

PULSE FREQUENCY

The frequency of impulses during pulse mode.

IMPULSE CURRENT

The maximum value of the electric current while in pulse mode.

BASE CURRENT

The current which maintains the arc while in pulse mode.

POWER FACTOR CORRECTION

This is the percentage difference of the time between the positive and negative direction of the current during a welding period. This feature allows control of the width of the welding seam and the depth of penetration.

Show moreShow less

CLEAN SCOPE - AC STROMBALANCE PARAMETER

This is the percentage difference between the positive and negative welding current value during a period.

2-STROKE

Start the weld by placing pressure on the torch button. Stop the process by releasing the button.

4-STROKE

By pressing the torch button the solenoid valve opens. allowing the gas to flow in. The gas pre-flow ignites the arc at the pre-set current. Releasing the burner button initiates a rise in the current to that of the pre-set welding current. The welding process stops once you press the burner button again.

Show moreShow less

HOT START

Through automatically boosting the tension at the ignition of the arc, this function facilitates the electrical arc ignition. After ignition, the unit automatically returns to the pre-set voltage.

Show moreShow less

ARC FORCE

The current value increases automatically when the arc is shorter.

ANTI-STICK

This function helps to prevent overheating of the electrode by switching off the welding current when the electrode sticks to the material.

TIG WELDING

A welding method in which the arc is maintained through an electrical current supplied from a non-consumable electrode. The arc is protected from the access of air by an inert gas.

Show moreShow less

MMA WELDING

Electrode welding with a coated electrode.

POWER SWITCH

"2T / 4T" SELECTION SWITCH

Choose between the 2T and 4T mode.

TIG AC/DC MODE SWITCH

TIG welding is divided into AC (alternating current) and DC (direct current) welding.

PULSE FUNCTION SWITCH

Used to switch the pulse function on and off.

SWITCH BETWEEN THE WELDING METHODS

By using the SHIFT key the welding mode can be selected.

PROG

The welding unit can internally save programs. You can start the desired program by pressing the button PROG.

SAVE

The unit can store several welding programs digitally under selected numbers, for example programs specific to the requirements of certain materials.

DISPLAY

Shows the welding / cutting parameters.

OVERLOAD / FAULT LED

The LED light indicates overheating or a malfunction.

Can I use this device to weld aluminium?

Yes, you can weld aluminium when working in TIG AC mode.
