Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc

Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc (2T / 4T: No)

Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc (Duty cycle [%]: 80)

Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc (ARC-Force: No)

Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc (Overcurrent: Yes)

Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc (Anti Stick: No)

1/6

On Sale

Seconds

Our factory seconds are generally refurbished customer returns or former display items. The products may have cosmetic defects but are technically flawless. As usual, we provide the normal right of return and warranty.

€386.00€482.00

Limited time offer€313.82 net (23% VAT excluded)

Lowest price in the 30 days before the discount: €479.00

Quantity

Last pieces! Items left: 1

FREE DELIVERYapprox. Tuesday, 3 March

Lowest price guaranteed

Key features

Powerful – the combination welding machine impresses with a welding current of 200 A and a cutting current of 50 A at an 80% duty cycle
4-in-1 – whether it's MIG/MAG, TIG Liftarc, MMA welding, or metal cutting, the multi-welding machine with integrated plasma cutter offers all possibilities
Precise – digital control panel with two rotary knobs for accurate adjustment of all parameters on the MIG TIG arc welder
Optimised – MAA welding with Hot Start and Arc Force guarantee clean weld seams
Effective – IGBT inverter delivers high efficiency, minimal interference, and rapid switching

Delivery details

Premium Guarantee

User Manual

Complete your set

Welding Cart - 3 levels - 65 kg - Product Image

On Sale

(28)

Welding Cart - 3 levels - 65 kg

€104.00€105.00

Lowest price in the 30 days before the discount: €105.00

Welding Helmet - COLOUR GLASS X-100B - coloured field of vision

€89.00

Technical details


(0) €386.00 Factory second Multiprocess Welder - MIG/MAG - 200 A - MMA - CUT 50 A - TIG Liftarc On Sale Seconds Currently seen	(0) €535.00 Factory second Multi Process Welder - TIG 200 A - duty cycle 60 % - cut 50 A - MIG/MAG 200 A On Sale Seconds	(0) €451.00 Factory second Multiprocess Welder - TIG AC DC - MMA - 250 A - CUT 50 A - Duty Cycle 60 % - Pulse On Sale Seconds
Dimensions (LxWxH)
43 x 19 x 36 cm	54 x 23 x 41 cm	52 x 22 x 40 cm
2T / 4T
No	Yes	Yes
Air consumption [l/min]
80 - 100	80 - 160	140 - 200
Air pressure
4.5 Bar	5 Bar	4 Bar
Anti Stick
No	Yes	No
ARC-Force
No	No	No
Automatic wire feed
No	Yes	No
Colour
White	White	White
Cut current
50 A	50 A	50 A
Cutting width [cm]
3	-	2
Duty cycle [%]
80	60	60
Efficiency [%]
90	80	83
Foot pedal
No	No	Yes
Gas magnetic valve
Yes	Yes	Yes
Ground cable
2 m	3 m	2 m
Hot Start
Yes	Yes	No
Ignition Plasma
Contact	Contact	HF
Ignition TIG
LIFT	HF	HF
Input power [kVA]
TIG 5.1 / MMA 8.2 / MIG 6.6 / CUT 7.1	9.6	TIG 4.5 / MMA 6.2 / CUT 6.5
Insulation class
F	F	F
Inverter type
IGBT	IGBT	IGBT
IP protection class
IP21S	IP21S	IP21S
Material
Carbon steel	Stainless steel Aluminium Carbon steel	Plastic Steel
Max cutting thickness
16 mm	15 mm	-
Max diameter of the wire spool
200 mm	200 mm	-
Maximum gas after-flow [s]
5	10	10
Maximum input current [A]
TIG 6-8 MIG 6-8 MMA 6-8 CUT 16	TIG 28 MMA 32 MIG 37 CUT 38	TIG 21 MMA 28 CUT 29
Maximum weldable thickness [mm]
TIG 6 - 8 / MMA 6 - 8 / MIG 6 - 8 / CUT 16	TIG 6 / MMA 8 / MIG 5 / CUT 18	TIG 20 / MMA 20 / CUT 20
Memory function
No	Yes	Yes
MIG/MAG cable
3 m	3 m	-
MIG/MAG welding current [A]
40 - 200	40 - 200	-
MMA cable
2 m	3 m	2 m
MMA welding current [A]
20 - 200	30 - 160	5 - 250
Norm Compliance
EN IEC 60974-1	EN IEC 60974-1	EN IEC 60974-1
Open circuit voltage [V]
TIG 65 / MMA 65 / MIG 65 / CUT 280	TIG 65 / MMA 65 / MIG 65 / CUT 293	TIG 60 / MMA 60 / CUT 260
Overcurrent
Yes	Yes	No
Overheat protection
Yes	Yes	Yes
Overvoltage protection
No	Yes	No
Plasma cable
4 m	5 m	4 m
Power factor
0.73	0.73	0.96
Pulse function
No	Yes	Yes
Rated Input current [A]
TIG 15.4 / MMA 24.5 / MIG 20.3 / CUT 21.7	TIG 15 / MMA 18 / MIG 20 / CUT 21	TIG 15.8 / MMA 16 / CUT 15.8
Recommended electrodes diameter [mm]
MIG 0.8 -1.0 / MMA 1.6 - 4.0 / TIG 1.6 - 2.4	3.2	MMA 1.6 - 4.0 / TIG 1.6 - 3.2
Shipping dimensions (LxWxH)
56 x 32 x 52 cm	64 x 34 x 48 cm	63 x 34 x 50 cm
Shipping weight
18.3 kg	28 kg	24.4 kg
Soft start
Yes	No	Yes
SYNERGY
Yes	Yes	No
TIG cable
4 m	4 m	-
TIG welding current [A]
15 - 200	10 - 200	5 - 250
Voltage [V]
220	230	230
Voltage Reduction Device (VRD)
No	Yes	No
Water cooling
No	No	No
Weight
10.42 kg	26.1 kg	20.5 kg
Welding methods
MIG TIG Lift MMA CUT	MIG MMA TIG CUT	MIG TIG CUT
Welding voltage [V]
MIG 16 - 25 / MMA 20.8 - 28 / TIG 10.6 - 18 / CUT 90 - 100	MIG 16 - 25 / MMA 20.8 - 28 / TIG 10.6 - 18 / CUT 90 - 100	MMA 27 / TIG 17 / CUT 100
Wire diameter [mm]
Φ0.8 / 1.0	0.8 / 1.0 / 1.2	-
Wire speed [m/min]
2 - 15	2 - 15	-

Compare more attributes

Delivery package

TRON TX200 multi process welder
MIG welding torch with hosepack (3 m)
Electrode holder with cable (1.8 m)
Earth clamp with cable (1.3 m)

Product Description

The powerful 4-in-1 multi process welding machine

The TRON TX200 welding machine from Welbach offers a professional, powerful, and high-quality solution for a range of repair and maintenance jobs. Weld with precision using shielding gas in the MIG/MAG welding process and TIG Liftarc, or with electrodes in MMA mode up to 200 A with an 80% duty cycle. Do you want to cut metals? Then use the 50 A integrated plasma cutter. At the core lies state-of-the-art inverter technology, enabling rapid switching between plasma, MIG/MAG, TIG Liftarc, and MMA processes, reliably implementing all parameters.

The multi process welder harnesses digital technology for perfect results

Use the digital control panel to select the welding method and set the welding current. MIG/MAG welding makes use of welding wire conveniently stored on a spool integrated within the device. The weld seam is protected during gas welding, with inert gases used for MIG and active gases for MAG. The device ensures premium welding quality, efficiency, and speed when working on steel structures or smaller welding jobs. For TIG Liftarc welding, shielding gas is necessary. This is directed straight to the weld seam via the welding torch.

When plasma cutting, manage the compressed air using the external pressure regulator and adjust the current to a maximum of 50 A. Do you want to weld outdoors, even in strong winds? Then the manual metal arc welding (MMA) method is what you're after. Achieve excellent welding results with a stable current strength when working with metals such as steel, iron, cast iron, nickel, or copper. Optimum welding results are achieved with MMA thanks to the Hot Start and Arc-Force functions.
