Product Number: EX20020229
|Model: TRON 200
Factory second Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A
![Factory second Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A (Duty cycle [%]: 30)](https://assets.expondo.com/asset/product_photos/10020229_photo_3?twic=v1/contain=104x104)
![Factory second Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A (Duty cycle [%]: 30)](https://assets.expondo.com/asset/product_photos/10020229_photo_3?twic=v1/contain=1024x500 "Factory second Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A (Duty cycle [%]: 30)")
![Factory second Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A (Duty cycle [%]: 30)](https://assets.expondo.com/asset/product_photos/10020229_photo_3?twic=v1/contain=40x40){kind=small}
On Sale
Seconds
Our factory seconds are generally refurbished customer returns or former display items. The products may have cosmetic defects but are technically flawless. As usual, we provide the normal right of return and warranty.
€406.00 €507.00
Lowest price in the 30 days before the discount: €589.00
Key features
- Versatile, thanks to TIG, MIG/MAG, MMA and FCAW
- Digital menu with 10 job programs
- Easily switch between the welding functions and between 2- / 4-stroke welding
- Comfortable MIG welding thanks to synergy function and option for spool gun
- MMA welding with VRD, anti-stick and arc force
Delivery details
User Manual
Complete your set
Technical details
 |  |
|---|---|
| €406.00 Factory second Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A On Sale Seconds Currently seen | €451.00 Factory second Multiprocess Welder - TIG AC DC - MMA - 250 A - CUT 50 A - Duty Cycle 60 % - Pulse On Sale Seconds |
Dimensions (LxWxH) | |
21.5 x 44.5 x 37.5 cm | 52 x 22 x 40 cm |
2T / 4T | |
Yes | Yes |
Air consumption [l/min] | |
- | 140 - 200 |
Air pressure | |
- | 4 Bar |
Anti Stick | |
Yes | No |
ARC-Force | |
Yes | No |
Automatic wire feed | |
Yes | No |
Colour | |
White | White |
Cut current | |
- | 50 A |
Cutting width [cm] | |
- | 2 |
Duty cycle [%] | |
30 | 60 |
Efficiency [%] | |
80% | 83 |
Foot pedal | |
No | Yes |
Gas magnetic valve | |
Yes | Yes |
Ground cable | |
3 m | 2 m |
Hot Start | |
No | No |
Ignition Plasma | |
- | HF |
Ignition TIG | |
LIFT | HF |
Input power [kVA] | |
TIG 5.6 / MMA 8.75 / MIG 7.5 | TIG 4.5 / MMA 6.2 / CUT 6.5 |
Insulation class | |
F | F |
Inverter type | |
IGBT | IGBT |
IP protection class | |
IP21S | IP21S |
Material | |
Steel | Plastic Steel |
Max diameter of the wire spool | |
200 mm | - |
Maximum gas after-flow [s] | |
1 | 10 |
Maximum input current [A] | |
TIG 26.8 MMA 41.7 MIG 35.7 | TIG 21 MMA 28 CUT 29 |
Maximum weldable thickness [mm] | |
TIG 10 / MMa 10 / MIG 12 | TIG 20 / MMA 20 / CUT 20 |
Memory function | |
No | Yes |
MIG/MAG cable | |
3 m | - |
MIG/MAG welding current [A] | |
50 - 200 | - |
MMA cable | |
3 m | 2 m |
MMA welding current [A] | |
40 - 200 | 5 - 250 |
Norm Compliance | |
EN IEC 60974-1 | EN IEC 60974-1 |
Open circuit voltage [V] | |
65 | TIG 60 / MMA 60 / CUT 260 |
Overcurrent | |
Yes | No |
Overheat protection | |
Yes | Yes |
Overvoltage protection | |
No | No |
Plasma cable | |
- | 4 m |
Power factor | |
0.73 | 0.96 |
Pulse function | |
No | Yes |
Rated Input current [A] | |
TIG 25.8 / MMA 38.3 / MIG 33.9 | TIG 15.8 / MMA 16 / CUT 15.8 |
Recommended electrodes diameter [mm] | |
MIG 0.6 - 1.0 / MMA 1.6 - 5.0 / TIG 1.6 - 2.4 | MMA 1.6 - 4.0 / TIG 1.6 - 3.2 |
Shipping dimensions (LxWxH) | |
59 x 41 x 42 cm | 63 x 34 x 50 cm |
Shipping weight | |
24.8 kg | 24.4 kg |
Soft start | |
Yes | Yes |
SYNERGY | |
No | No |
TIG cable | |
3.8 m | - |
TIG welding current [A] | |
15 - 200 | 5 - 250 |
Voltage [V] | |
230 | 230 |
Voltage Reduction Device (VRD) | |
Yes | No |
Water cooling | |
No | No |
Weight | |
19.2 kg | 20.5 kg |
Welding methods | |
MIG MMA TIG | MIG TIG CUT |
Welding voltage [V] | |
15 - 24 | MMA 27 / TIG 17 / CUT 100 |
Wire diameter [mm] | |
0.6 / 0.8 / 0.9 / 1 | - |
Wire speed [m/min] | |
2 - 14 | - |
Compare more attributes
Delivery package
- Combined welder TRON 200
- TIG cable assembly, 3.8 m
- MIG cable assembly, 3 m
- MMA welding cable with electrode holder, 3 m
- Grounding cable with clamp, 3 m
- 3 clamping sleeves - 1.6 / 2.0 / 2.4 mm
- Clamping sleeve housing
- 3 ceramic gas nozzles (4 mm, 5 mm, 6 mm)
- TIG electrode, Ø 2 mm
- MIG gas nozzle
- MIG contact tip, Ø 0.8 mm
- Long torch cover
- Short torch cover
- User manual
Product Description
Combined Welder - Digital - TIG - MIG/MAG - MMA - 200 A
The combined welder TRON 200 with digital menu navigation offers the right welding process for every metalwork. Thin sheets or robust steel girders, with or without gas, on the construction site or in the workshop, with MIG/MAG, TIG, MMA or FCAW welding processes -- this welder has all the options for efficiently and safely welding metals together. With its powerful IGBT inverter, this welder is able to quickly switch between welding processes, thus delivering high-quality welds with a very low error rate.
With MIG/MAG welding, gases protect the weld seam - with MIG it is inert gases, with MAG active gases. With the method you weld quickly and efficiently. The wire feed has a speed of 2 to 14 m/min and is designed for wires with a diameter of 0.6 to 1 mm. You can use a spool gun (not included in the scope of delivery) for MIG welding, which feeds the welding wire directly to the torch.
Thanks to the synergy function, you can optimally coordinate all parameters in MIG/MAG welding. Select the welding current between 50 and 200 A and the welding machine sets the remaining parameters such as welding voltage and wire speed automatically.
With FCAW welding, you create weld seams using a cored wire – without additional gas. This makes the method very handy - perfect for small repairs outdoors.
Customers interested in this product also viewed
Ratings & reviews
Ratings & reviews
Sort by :
Frequently asked questions
Does this device have an anti-stick function?
Yes, the anti-stick function switches on automatically when MMA welding and prevents the electrode from sticking to the workpiece.
Can you use this welder to weld in TIG mode?
Yes, simply select TIG mode from the digital menu. The device uses lift-arc start for this welding process, which has less effect on sensitive devices nearby.
